Quotation list of Detachable container house
No.	Component	Specification	Unit	Quantity	Remarks
1	Column	2480*2.3	Strip	4	High of Beam:195MM Sink:65MM Thickness:2.3MM Hot-dip Galvanized Sheet Profile
2	Bottom Beam	5630*2.3	Strip	2
3	Bottom Beam	2680*2.3	Strip	2
4	Top Beam	5630*2.3	Strip	2
5	Top Beam	2680*2.3	Strip	2
6	Corner Piece	1951654	Piece	8
7	Top Platen Slot	5730*1.2	Strip	2	Galvanized
8	Top Platen Slot	2790*1.2	Strip	2
9	Corner Fitting	1201.22530	Strip	1
10	Bottom Beam SquareTube	100502980*1.3	Strip	9	Galvanized
11	Top Beam SquareTube	50502800*1.8	Strip	2	Galvanized, with Card Slots On Both Sides
12	Top Beam SquareTube	80401880*1.5	Strip	3	Galvanized
13	Top Beam Square Tube	604018801.5	Strip	6	Galvanized
14	Main Frame Bolt	ST100*30	Piece	64	Carriage Bolt
15	Bottom Beam Bolt	ST100*80	Piece	18
16	Floor	2800114618	Sheet	5	MGO Fireproof Board
17	Structural Adhesive		Piece	5
18	Ceiling Board	27882000.3	Piece	29
19	Roof Tile	29209500.5	Piece	6
20	Roll Felt	20M	Roll	1
21	Hardware		Carton	1
22	Butyl Rubber Strip		M	12
23	Corner Fitting	38	Strip	2
24	Door	925*2050	Piece	1
25	Window	925*1200	Piece	2
26	Board Material	256095050	Piece	15	0.276Glass Wool Board
27	Board Material	138095050	Piece	2	0.276Glass Wool Board
28	Board Material	46095050	Piece	1	0.276Glass Wool Board
